Shale Crushing And Grinding Machines

22/05/2024 admin

Shale is a fine-grained sedimentary rock that is formed from the compaction of silt and clay-size mineral particles, known as mud. It is characterized by its laminated structure and can easily split into thin layers.

Crushing and grinding shale is essential for producing materials like shale oil, gas, and other by-products. The process involves several stages, each requiring specific types of machinery to achieve the desired size reduction and preparation of the shale for further processing.

Crushing and grinding machines are used to reduce the size of the shale particles and prepare them for further processing. These machines can be classified into two main categories: crushing machines and grinding machines.

Shale Crushing Machines

Jaw Crusher

  • Description: Heavy-duty machines with a fixed and a movable jaw.
  • Application: Primary crushing of large shale rocks.
  • Operation: The material is crushed between the fixed jaw and the movable jaw, reducing it to a manageable size.

Hammer Crusher

  • Description: Machine consists of a series of hammers mounted on a rotating shaft.
  • Application: Primary or secondary crushing of large shale chunks.
  • Operation: The material is struck by the rapidly rotating hammers. The crushed material is then thrown against the breaker plates inside the machine, which further break down the material. The process continues until the material is reduced to the desired size and can pass through the openings in the grate bars at the bottom of the crusher.

Cone Crusher

  • Description: Machines with a cone-shaped crushing surface and a concave surface.
  • Application: Secondary and tertiary crushing for finer size reduction.
  • Operation: The material is crushed between the cone and the concave surfaces by compressive forces.

Impact Crusher

  • Description: Utilize impact rather than pressure to crush materials.
  • Application: Secondary crushing of softer shale rocks.
  • Operation: Material is fed into a chamber where it is struck by high-speed rotating hammers or blow bars, causing it to break along natural fissures.

Roll Crusher

  • Description: Feature two rotating rollers.
  • Application: Secondary or tertiary crushing of medium-hard shale.
  • Operation: Material is fed between the rollers, which rotate in opposite directions to pull the material through and crush it.

Shale Grinding Machines

Ball Mill

  • Description: Cylindrical devices containing steel balls as grinding media.
  • Application: Fine grinding of shale to produce powder.
  • Operation: The rotating cylinder causes the balls to tumble and crush the shale.

Hammer Mill/Coarse Powder Mill

  • Description: Machines with rotating hammers.
  • Application: Coarse to fine grinding of shale.
  • Operation: The hammers strike the shale at high speed, shattering it into fine particles.

Raymond Mill

  • Description: Vertical mills known for their efficiency and low power consumption.
  • Application: Fine grinding of shale into powder.
  • Operation: Rollers grind the shale against a rotating table, with built-in classifiers ensuring uniform particle size.

Ultrafine Grinding Mill

  • Description: Mills designed for extremely fine powder production.
  • Application: Used in industries requiring very fine materials, such as papermaking, coating, plastice, costometic or high-tech ceramics.
  • Operation: High-speed rotating discs or other mechanisms achieve ultrafine grinding.

Ultrafine Vertical Grinding Mill

  • Description: Utilize large rollers to crush and grind material against a rotating table.
  • Application: Fine grinding of shale for industrial applications.
  • Operation: The material is ground between the rotating table and the rollers.

Shale Crushing and Grinding Process Workflow

  • Primary Crushing: Large shale rocks are fed into jaw or hammer crushers for initial size reduction.
  • Secondary Crushing: Cone or impact crushers further reduce the size of the material.
  • Screening and Classification: Crushed shale is screened to separate it into different-size fractions.
  • Grinding: The screened shale is ground into a fine powder using ball mills, hammer mills, ultrafine grinding mill, or vertical roller mills.
  • Classification: The ground material is classified to ensure uniform particle size using screens or air classifiers.
  • Collection and Packaging: The fine shale powder is collected and packaged for further processing or direct use.

By using the appropriate crushing and grinding machinery, the shale can be efficiently processed to meet the specific requirements of various industrial applications.
